Cangzhou Ouguan Packing Machinery Co.,Ltd always keeps well informed about the technical development and new product R&D, which guarantees we can develop new products on a regular basis. The research and development team is the core competence to automatic carton box rotary diecutter machine corrugated box printing slotter die cutter machine. It enables us to become a leader in the flexo printer slotter die-cutter machine. At present, Cangzhou Ouguan Packing Machinery Co.,Ltd are still a growing enterprise with a strong ambition to become one of the most competitive enterprises in the market. We will continue to research and develop new technologies for the birth of new products. Also, we will grasp the precious tide of opening up and reform to attract customers all over the world.
|Applicable Industries:||Hotels, Garment Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Retail, Food Shop, Printing Shops, Food & Beverage Shops, Other, Advertising Company||Showroom Location:||None|
|Condition:||New||Product Type:||cardboard machine|
|Processing Type:||Printing Machine||Place of Origin:||Hebei, China|
|Dimension(L*W*H):||Depend on model||Weight:||65000 kg|
|Warranty:||1 Year||Production Capacity:||100-150 pcs/min|
|Machinery Test Report:||Provided||Video outgoing-inspection:||Provided|
|Marketing Type:||New Product 2020||Warranty of core components:||1 Year|
|Core Components:||PLC, Pressure vessel, Other, Engine, Gear, Motor, Pump, Bearing, Gearbox||Name:||Printing Die Cutting slotting Machine|
|Color:||Customer's Requirements||Suitable for:||Cardboard|
|Control:||PLC+Touch Screen||Key Selling Points:||Auto|
|Speed:||150 pcs/min||Function:||Printing Carton|
|Type:||Automatic||Keyword:||Ink Printing Die-Cutting Machine|
The whole machine is adopted international famous brand appliances "Schneider" .The quality is stable and reliable.
The machine shaft, roller are adopted high quality steel, grinding processing, high precision computer dynamic balancing correction and surface hard chromium plating.
The engine drive gear is adopted 40Cr, the shaving machining nitrogen treatment, tinted with high precision.
Machine transmission parts (shaft, gear joint) is adopted free key connection (LOCK -ALX),clears the connection gap.lt is suitable for long-term high speed running with high torque.
The machine drive bearing ,important driving parts adopt three big domestic famous brand:Hava los,simple maintenance,long service life.
The engine lubrication system is adopted automatic spray type lubrication, equipped with auto oil level balance system.
It adopts Working gap adjustment, self-locking type worm wheel and worm gear device , quick performance and convenient adjustment.
The main motor is adopted frequency conversion control.Ilt makes start, running more steadily and saves more energy.
Rotary die-cutting department and rotary slotting department is optional for you.
Option : ceramic anilox roller stacking.
|Color group||to be configured according to user's needs|
|Width of machine inside||2600mm||2800mm||3000mm|
|Max. paper size||1200×2400mm||1400×2600mm||1600×2800mm|
|Max. printing size||1200×2300mm||1400×2500mm||1600×2700mm|
|Skip feeding paper||1400×2400mm||1600×2600mm||1800×2800mm|
|Printing plate thickness||7.2mm||7.2mm||7.2mm|
|Max. die cutting size||1200×2300mm||1400×2500mm||1600×2700mm|
Get in touch
We wholeheartedly cooperate with our customers and will continue to improve product quality and more perfect after-sales service to meet customer needs.
